In this paper, a shunt active power filter (SAPF) based on adaptive hysteresis band current controller (HBCC) is proposed for limiting the harmonics in load current and also compensate the reactive power for 3 phase non-linear load. The HBCC calculate the active power and reactive power, transforms them in d, q and 0 components using Clarke's transformation then calculates the compensating values of active and reactive power to inject them further in system.
The HBCC determines the switching signals of the SAPF, and the algorithm based on an extension of synchronous reference frame theory (d-q-0) is used to determine the suitable current reference signals. The results of simulation study of SAPF control technique presented in this paper is found quite satisfactory to eliminate harmonics and reactive power components from utility current.
by Zahid Hassan | Gagan Deep Yadav "Reactive Power Compensation and Limiting Harmonic Current using Shunt Active Power Filter"
Published in International Journal of Trend in Scientific Research and Development (ijtsrd), ISSN: 2456-6470, Volume-2 | Issue-4 , June 2018,
URL: http://www.ijtsrd.com/papers/ijtsrd12958.pdf
Direct Link - http://www.ijtsrd.com/engineering/electrical-engineering/12958/reactive-power-compensation-and-limiting-harmonic-current-using-shunt-active-power-filter/zahid-hassan
